Infrastructure

The infrastructure in LACI is purchased via funding support from


1. LASERS
INRS

(1) Single-wavelength CW laser
          471 nm                        532 nm                        589 nm                        671 nm
CW laser_671 CW laser_532  111.jpg  CW laser_473
Vendor: CNI
Power: 200 mW
INRS

(2) Tunable-wavelength CW laser
aaa
Vendor: M Squared Sostics 4000
Untitled1
INRS

(3) 532-nm nanosecond pulsed laser
Pulse laser_523 nm.jpg
Vendor: Spectra-Physics
Maximum power: 40 W
Pulse duration: 3-50 ns
Repetition rate: 10 kHz – 1 MHz

(4) 559-nm nanosecond pulsed laser
fff
Vendor: Tomowave
333
INRS

(5) Dye laser
eee
Vendor: Spectra-Physics
222
INRS

2. CAMERAS


(1) Scientific CMOS camera
bbb
Vendor: Andor
Untitled1
INRS

(2) Electron-multiplying CCD camera
NUVU EMCCD_front view.jpg NUVU EMCCD.jpg
Vendor: NuVu 1024

(3) High-speed-interface CCD camera (x2)
ddd
Vendor: Optronics CP70-1HS-M-1900
111

(4) High-speed color camera
Vendor: PCO

INRS

3. MICROSCOPE


(1) Upright microscope
ccc
Vendor: Olympus BX51W
Untitled1
INRS



4. MODULATORS


(1) .7″ Digital micromirror device (x3)
111.jpg  hhh
Model No: DLi D4100 and ViALUX V-7000

(2) .45″ Digital micromirror device (x4)
Vendor: Ajile Light Industries
Max. refreshing rate: 6600 fps
On-board memory: 1 GB (7000 frames)

(3) Electro-optic modulator

(4) Acoustic-optic modulator
Acousto-optic deflector.jpg AOD_driver.jpg
Vendor: Gooch & Housego

INRS

5. ELECTRONICS


(1) Delay generator
Delay generator DG645.jpg
Vendor: Stanford Research Systems
Part No.: DG645 (x2) and DG 355
